Torque screwdriver iTorque® with digital display, maximum torque: 150cNm
Article no.: 659935 150
Article code:
Click to enlarge image
Click to enlarge image
Calibration alarm after 5000 tightening operations.
Click to enlarge image
No additional tool required for setting
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Click to enlarge image
Product details
Technical Data
| Number of batteries contained | 1 pcs. | |
| Type of battery | lithium (Li) | |
| International size | other size | |
| Series | iTorque® | |
| Manufacturer’s designation | iTorque® | |
| Power supply | battery-powered | |
| Adjustable trigger value | adjustable; adjustable; adjustable; adjustable | |
| Unit of measure for torque | cNm; cNm; lbf in; lbf in; cNm; cNm; lbf in; lbf in; cNm; cNm; lbf in; lbf in; cNm; cNm; lbf in; lbf in | |
| Min. torque, cNm | 40; 40; 40; 40; 40; 40; 40; 40 | |
| Max. torque, cNm | 150; 150; 150; 150; 150; 150; 150; 150 | |
| Setting the trigger value | digitally adjustable; digitally adjustable | |
| Bit holder, exchangeable blade | D 6; F 6 | |
| Unit of measure for scale graduations | cNm | |
| Scale graduation, 1 graduation | 1 cNm | |
| Torque unit | Nm; cNm; lbf in | |
| Data can be recorded | no | |
| Trigger principle | mechanical short travel release | |
| Trigger signal | acoustic; haptic | |
| Feedback | triggering; triggering | |
| Content | single part | |
| Can be calibrated | yes | |
| Type of product | torque screwdriver; torque screwdriver | |
| Direction of tightening | right-hand | |
| Shape of connection | exchangeable blade | |
| Measurement technology | mechanical | |
| Measuring functions | torque | |
| DIsplay | digital | |
| Torque range (min.) | 0.4 Nm | |
| Torque range (max.) | 1.5 Nm | |
| Manufacturer’s test certificate | yes | |
| Standard | DIN EN ISO 6789-1; DIN EN ISO 6789-2 | |
| Overall length | 134 mm; 134 mm | |
| Total weight | 322 g |
Identification & Classification
| Article number | 659935 150 | |
| EAN / GTIN | 4010995368869 | |
| Manufacturer number | 36886 | |
| Manufacturer/responsible person | Wiha Werkzeuge GmbH, Obertalstraße 3-7, 78136 Schonach, Germany, www.wiha.com |
Description
Version:
High-quality comfortable metal-plastic composite handle ensures ergonomic working and easy application of the set torques. Quick and easy reading and setting via the large digital display. Automatic switch-off after 15 seconds (battery life at least 1 year). The battery can be changed at the factory or during recalibration. Display changeover between Nm and lbf in. Includes bit-holder blade No. 659932 to take 1/4 inch bits.
Units of measure: Nm, lbfin
Units of measure: Nm, lbfin
Advantage:
An integral counter function records the number of tightening operations, providing the basis for monitoring by test instruments.
Function:
On reaching the set torque value, the screwdriver can be felt and heard to trigger and is then again immediately ready for use.
Application:
For controlled tightening of screws to a pre-set torque.
Standard:
Tested to DIN EN ISO 6789.
