Reversible precision ratchet, 1/4 inch, Type: 1/4
Article no.: 632389 1/4
Article code:
- Square drive: 1/4
Offers
Product details
Technical Data
| Square drive | 1/4 in | |
| Standard | DIN 3120 | |
| overall length | 116 mm | |
| No. of teeth | 90 | |
| Working angle | 4 degrees | |
| Material | Chrome vanadium steel | |
| Surface | chrome-plated | |
| Type of product | Ratchet | |
| USP1 | Precision, reversible, | |
| USP2 | 90 teeth, length 116 mm |
Identification & Classification
| Article number | 632389 1/4 | |
| EAN / GTIN | 4000896226917 | |
| Manufacturer number | 863HP | |
| Manufacturer/responsible person | HAZET-WERK Hermann Zerver GmbH & Co. KG, Güldenwerther Bahnhofsstraße 25-29, 42857 REMSCHEID, Germany, www.hazet.com |
Description
Version:
Material selection and special forging method guarantee optimal functioning and long life.
With reversing lever for right-hand and left-hand threads, working arc 4°.
With reversing lever for right-hand and left-hand threads, working arc 4°.
Standard:
Sturdy all-steel ratchet in short slim design Particularly suitable for use in restricted spaces. With ergonomic finger supports at the end of the handle. 15° offset.
Material:
Chrome vanadium steel, chrome-plated.
Suitable for:
Manual use.
